This software package consists of multiple different sub-tools.

Thus, a combined electromagnetic and circuit optimization task can easily be defined, where the typical goal is to design an antenna or antenna system such that the total efficiency is maximized, using a realistic matching circuit with available off-the-shelf discrete component models. For the simulations in this work the software 'CST Studio Suite' 140 was employed. Maka yang pertama dilakukan adalah memasang libraries install libraries, lalu ikuti langkah-langkah yang seterusnya dengan menekan tombol next.

In addition, CST MICROWAVE STUDIO's template based post-processing tools can be used to automatically apply Optenni Lab within a parameter sweep or an optimization task in CST MICROWAVE STUDIO. Post-processing templates for parameter sweeps and optimization in CST MICROWAVE STUDIO Synthesize the circuits in Optenni Lab, and right click any of the generated circuits and select "Transfer circuit to CST DESIGN STUDIO" whereafter the circuit is constructed on the CST DESIGN STUDIO schematic, connected to external ports and simulated.In CST MICROWAVE STUDIO® use the command "Home->Macros->Matching Circuits->Launch Optenni Lab" to launch Optenni Lab using the simulated impedance and radiation pattern data.Launching Optenni Lab from CST STUDIO SUITEĬustomers who have both CST STUDIO SUITE® and Optenni Lab licenses can easily construct matching circuits in Optenni Lab using the impedance and radiation pattern data calculated in CST STUDIO SUITE and return the optimized matching circuits back to CST DESIGN STUDIO™.
